Gulfstream GV
One of the fastest of all business jets, the record-breaking Gulfstream GV offers an unmatched combination of speed, safety, comfort, and range.
13 PAXPassengers
approx.
approx.
1.89 mCabin Height
approx.
approx.
6.40 cu mBaggage Volume
(max)
(max)
12038 kmRange
depending on weight and weather
depending on weight and weather
Gulfstream GV
Specifications
Manufacturer
Manufacturer | Gulfstream |
Production Years | 1995 - 2002 |
Powerplant
Engine Manufacturer | Rolls Royce |
Engine Model | BR 710-A1-10 |
Engine Quantity | 2 Engines |
Thrust | 6691 kg |
Exterior
Wingspan | 28.50 m |
Fuselage | 29.38 m |
Interior
Number of Passengers (Pax) | 13 Passengers |
Cabin Width | 2.23 m |
Cabin Length | 15.27 m |
Cabin Height | 1.89 m |
Total Cabin Volume | 51.31 cu m |
Total Baggage Volume | 6.40 cu m |
Speed
Normal Cruise Speed | 904 kph |
Long-Range Cruise Speed | 850 kph |
Maximum Cruise Speed | 941 kph |
Range Map
Optimum Cruise Range | 12038 km |
Maximum Cruise Range | 11297 km |
Seats Full Range | 11575 km |
Ferry Range | 12362 km |
Weight
Ramp Weight | 41232 kg |
Max Gross Takeoff Weight | 41051 kg |
Azami İniş Ağırlığı | 34156 kg |
Max Landing Weight | 19278 kg |
Usable Fuel Weight | 18598 kg |
Powerplant
Engine Manufacturer | Rolls Royce |
Engine Model | BR 710-A1-10 |
Engine Quantity | 2 Engines |
Thrust | 14750 lb |
Exterior
Wingspan | 93.5 ft |
Fuselage | 96.4 ft |
Interior
Number of Passengers (Pax) | 13 Yolcu |
Cabin Width | 7.3 ft |
Cabin Length | 50.1 ft |
Cabin Height | 6.2 ft |
Total Cabin Volume | 1812 cu ft |
Total Baggage Volume | 226 cu ft |
Speed
Normal Cruise Range | 488 kts |
Long-Range Cruise Speed | 459 kts |
Maximum Cruise Speed | 508 kts |
Range Map
Optimum Cruise Range | 6500 nm |
Maximum Cruise Range | 6100 nm |
Seats Full Range | 6250 nm |
Ferry Range | 6675 nm |
Weight
Ramp Weight | 90900 lb |
Max Gross Takeoff Weight | 90500 lb |
Max Landing Weight | 75300 lb |
Usaful Fuel Weight | 42500 lb |
Usable Fuel Weight | 41000 lb |
Cabin Layout
Gulfstream GV
Range Map
Gulfstream GV range maps will be here very shortly.For detailed information about Gulfstream GV, please contact us.
